Reverse Vending Machine for Plastic Bottles

Waste sorting, recycling, and green consumption concepts are becoming increasingly popular. Our reverse vending machine for plastic bottles feature automatic identification, weighing and calculation, and volume reduction. Get a quote now! WhatsApp/Tel: +86 138 3838 5752

Parameters of Reverse Vending Machines

Type	Single Opening
Inner Bin Capacity	512L
Screen Size	10.1″ / 21.5″
Box Material	Galvanized steel / Stainless steel with powder coating
Compactor	Customized (consult customer service) – 1 unit
External Dimensions	960 (W) × 960 (D) × 1860 (H) mm (including base/casters)
Standby Power	60W

Request Quotations! WhatsApp/Tel: 86 138 3838 5752

Recycling Vending Machine Application Scenarios

• Shopping malls, supermarkets, and commercial complexes: Placed near entrances or parking lots for convenient disposal by consumers.
• Campuses and educational parks: Can be integrated with point-based reward systems to promote environmental education and “green campus” initiatives.
• Residential communities and streets: Integrated with waste sorting programs.
• Tourist attractions and exhibition centers: Addressing the collection of beverage bottles and aluminum cans in high-traffic areas.
• Factories, industrial parks, and office buildings: Centralized collection of beverage packaging used by employees.
• Stations, airports, and service areas: Improving environmental management efficiency in public spaces.

Reverse Vending Machine for Plastic Bottles Design

Overall Design

The unit features a bottom-corner structure and offers a capacity of up to 512L. Its single-inlet design ensures intuitive visibility for users. The housing comes in galvanized steel or stainless steel, with material thickness options of 1.2 mm, 1.5 mm, and 2.0 mm. You can choose finishes such as hairline brushing, polishing, baked enamel, sandblasting, anti-rust coating, or screen printing to meet your specific requirements. Casters at the base make the device easy to move.

Device Screen

Screen sizes available: 10.1-inch or 21.5-inch. The touchscreen utilizes a wide-viewing-angle LCD display with multi-point interference resistance, anti-glare capabilities, and capacitive touch technology. It meets ESD Level 3, EFT Level 3, and Surge Level 3 protection standards. Screen brightness is approximately 450 cd/m².

Lighting System

The inlet is equipped with a tri-color light strip that indicates the device’s status—such as standby, processing, successful deposit, or maintenance required—through different colors.

Bottle Return Machines Features

Automatic Weighing and Compression

After the user deposits a plastic bottle or aluminum can, the device collects data through scanning, counting, and weighing. The screen displays the weight, quantity, and corresponding price of the recyclables. A built-in electric compressor compresses the recyclables to reduce their volume.

Opening Methods

This device supports several opening methods, including card swiping, QR code scanning, facial recognition, button operation, and sensor activation.

Back-end Management

The accompanying intelligent operation and maintenance management platform enables 24/7 real-time monitoring of the equipment. Operators can view information such as equipment online status, operating location, fault alarms, waste type, waste weight, collection records, points cashback, and scheduled door-to-door collection orders.

About Foodline

If you’re planning a community waste sorting or recycling station, this smart beverage bottle and aluminum can recycling bin can be customized to your site size and needs, providing you with a tailored solution. Our best-selling products also include book vending machines and cosmetics vending machines. Inquire now! WhatsApp/Tel: +86 13838385752
